5KVA 5000VA AVR AVS AC220V AC110V SVC TND Series Home Appliance Single Phase Voltage Stabilizer

5KVA 5000VA AVR AVS AC220V AC110V SVC TND Series Home Appliance Single Phase Voltage Stabilizer

Place of Origin:

Shanghai, China

Brand Name:

Ewen Electrical

Certification:

CE

Model Number:

TND(SVC)-5KVA

Contact Us
Request A Quote
Product Details
Current Type:
AC
Usage:
Voltage Stabilization
Phase:
Single Phase
Rated Capacity:
5KVA
Input Voltage:
220V±20%
Output Voltage:
220V
Frequency:
50-60HZ
Display:
Analog Meters
Response Time:
<1.5s
Type:
Servo Motor Type
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiation
Packaging Details
Non-fumigation Plywood Case / Pallet
Delivery Time
According to Quantity
Payment Terms
T/T
Supply Ability
50000 pcs per Month
Product Description

5KVA 5000VA AVR AVS AC220V AC110V SVC TND Series Home Appliance Single Phase Voltage Stabilizer



1. PRODUCT PROFILE



TND series single phase voltage regulator is mainly composed of copper coil, servo motor, auto-control circuit, carbon brush, and display system etc. When voltage fluctuates or load varies, the control circuit would give out signal to servo motor to drive the carbon brush to move along the surface of the copper coil, so as to maintain the voltage stabilized. TND voltage regulator is widely applied in places which needs stable single phase voltage.



5KVA 5000VA AVR AVS AC220V AC110V SVC TND Series Home Appliance Single Phase Voltage Stabilizer 0

2. PRODUCT PARAMETERS



Product name Single Phase Voltage Stabilizer
Rated capacity 5KVA
Input voltage 176-264V Could be customized
Output voltage 220V Could be tailored
Output current 22A
Working frequency 50HZ/60HZ
Display system Pointer meter display
Output accuracy ±2%
Insulation class Class F
Response speed ≤1.5s
Insulation resistance >2MΩ
Cabinet color RAL 7035 (Could be customized)
Protection class IP21(Could be customized)
Working temperature -10°C-+45°C
Dielectric strength Lasting for one minuet with working frequency 2000VAC
Protection functions Over voltage, under voltage, short circuit, over current (Could be customized)



3. PRODUCT FEATURES



Single phase voltage stabilizer TND(SVC)-5000VA/5KVA has such features as described as follows:



• Fast response speed

• High output accuracy

• Wide input voltage range

• No additional waveform distortion

• Sound voltage regulation performance

• Suitability for various loads

• High efficiency

• Strong instantaneous over-load bearing capability

• Suitability for constant work

• Over-voltage protection

• Under-voltage protection

• Over-current protection

• Over-load protection

• Short circuit protection

• Auto voltage regulation

• Long service lifetime



4. PRODUCT REFERENCE DIMENSION



5KVA 5000VA AVR AVS AC220V AC110V SVC TND Series Home Appliance Single Phase Voltage Stabilizer 1



5. COMPANY INTRODUCTION



5KVA 5000VA AVR AVS AC220V AC110V SVC TND Series Home Appliance Single Phase Voltage Stabilizer 2



6. OUR SERVICES



① Sampling service could be provided.

② Technical guidance would be offered.

③ OEM/ODM services are available.

④ Installation guidance could be provided.



7. PRODUCT CASES



Ewen (Shanghai) Electrical Equipment Co., Ltd. is a voltage stabilizer manufacturer with rich experience. The following pictures show voltage stabilizer cases we have ever had. Except single phase voltage stabilizer, we also provide three phase voltage stabilizer, ac power stabilizer, high power voltage stabilizer, and voltage regulator etc.



5KVA 5000VA AVR AVS AC220V AC110V SVC TND Series Home Appliance Single Phase Voltage Stabilizer 3
